Rectified Alcohol Tank TAR-1 EJB-176
Manufacturer: NG
Model: Vertical
Capacity: 40 m³
Anhydrous Alcohol Tank TAA-1 EJB-177
Manufacturer: NG
Model: Vertical
Capacity: 40 m³
Regenerated Phlegm Tank TFR-1 EJB-178
Manufacturer: NG
Model: Vertical
Capacity: 19 m³
Alcohol Evaporator EV-BP1 (EVP1) EJB-179
Manufacturer: NG
Model: Vertical
Capacity: 6.42 m³
Alcohol Superheater EV-AP2 (EVP2) EJB-180
Manufacturer: NG
Model: Vertical
Capacity: 1.62 m³
Regenerated Phlegm Heater AFR-1 EJB-199
Manufacturer: Aalfa Laval
Model: Plates – TL10-BFM
Capacity: 170 liters
Plate Heat Exchanger EJB-182
Manufacturer: Alfa Laval
Model: Plates – TL10-BFM
Capacity: 55 liters
Alcohol Vapor Condenser CVA-1 EJB-183
Manufacturer: NG
Model: Vertical
Dehydration Columns CRD-1
Tag: EJB-184
Manufacturer: NG
Model: Vertical
Capacity: 131.7 m³
Dehydration Columns CRD-2 EJB-185
Manufacturer: NG
Model: Vertical
Capacity: 131.7 m³
Vacuum Phlegm Condenser CFV-1 EJB-186
Manufacturer: NG
Model: Vertical
Vacuum Phlegm Condenser CFV-2 EJB-351
Manufacturer: NG
Model: Vertical
Anhydrous Alcohol Condenser CAA-1 EJB-187
Manufacturer: NG
Model: Vertical
Capacity: 1.01 m³
Anhydrous Alcohol Condenser CAA-2 EJB-198
Manufacturer: NG
Model: Vertical
Capacity: 1.01 m³
Anhydrous Alcohol Cooler RAA-1 EJB-181
Manufacturer: Alfa Laval
Model: Plates – TL10-BFM
Capacity: 127 liters
Gas Washing Tower and Alcohol Recovery CLV-1 EJB-200
Manufacturer: NG
Condensate Tank CFV-1 and TK-01 EJB-216
Manufacturer: NG
Model: Vacuum
Capacity: 1 m³
Condensate Tank CAA-1 and TK-02 EJB-217
Manufacturer: NG
Model: Vacuum
Capacity: 1 m³
Dehydration Column Purge Tank TK-05 EJB-201
Manufacturer: NG
Capacity: 0.4 m³
Phlegm Collection Vessel TK-06 EJB-202
Manufacturer: NG
Capacity: 0.9 m³
Flash Drum BA FL-1 EJB-218
Manufacturer: NG
Capacity: 40 m³
Vacuum Pump BV-01 EJB-203
Manufacturer: OMEL
Model: BLA 250/240
Rectified Alcohol Transfer Pump No. 01 BA-02 EJB-344
Manufacturer: Imbil
Model: INI 40/125
Capacity: 42 m³/h
Electric Motor – Pump No. 01 EJB-344.1
Manufacturer: WEG
Model: 3 100L
Power: 5 kW
Rectified Alcohol Transfer Pump No. 02 BA-02 EJB-345
Manufacturer: Imbil
Model: INI 40/125
Capacity: 42 m³/h
Electric Motor – Pump No. 02 EJB-345.1
Manufacturer: WEG
Model: 3 100L
Power: 5 kW
Anhydrous Transfer Pump No. 01 to Tank TAA-1 and BA-03 EJB-346
Manufacturer: Imbil
Model: 40/120
Capacity: 15 m³/h
Anhydrous Transfer Pump No. 02 to Tank TAA-1 and BA-03 EJB-347
Manufacturer: Imbil
Model: 40/120
Capacity: 15 m³/h
Anhydrous Alcohol Pump No. 01 for Storage BA-04 EJB-348
Manufacturer: Imbil
Model: 50/160
Capacity: 52 m³/h
Electric Motor – Pump No. 01 EJB-348.1
Manufacturer: WEG
Model: 3 132M
Power: 10 kW
Anhydrous Alcohol Pump No. 02 for Storage BA-04 EJB-349
Manufacturer: Imbil
Model: 50/160
Capacity: 52 m³/h
Electric Motor – Pump No. 02 EJB-349.1
Manufacturer: WEG
Model: 3 132M
Power: 10 kW
Regenerated Phlegm Pump No. 01 BA-05 EJB-350
Manufacturer: Imbil
Model: INI 32/125
Capacity: 13 m³/h
Electric Motor – Pump No. 01 EJB-350.1
Manufacturer: WEG
Model: 3 90L
Power: 3 kW
Regenerated Phlegm Pump No. 02 BA-05 EJB-352
Manufacturer: Imbil
Model: INI 32/125
Capacity: 13 m³/h
Electric Motor – Pump No. 02 EJB-352.1
Manufacturer: WEG
Model: 3 90L
Power: 3 kW
Condensate Transfer Pump No. 01 BA-09 EJB-353
Manufacturer: Imbil
Model: INI 32/125
Capacity: 22 m³/h
Electric Motor – Pump No. 01 EJB-353.1
Manufacturer: WEG
Model: 3 90L
Power: 3 kW
Condensate Transfer Pump No. 02 BA-09 EJB-354
Manufacturer: Imbil
Model: INI 32/125
Capacity: 22 m³/h
Electric Motor – Pump No. 02 EJB-354.1
Manufacturer: WEG
Model: 3 90L
Power: 3 kW
Stainless Steel Tank EJB-204
Model: Vertical/Open
Capacity: 1.5 m³
Centrifugal Pump EJB-355
Manufacturer: Imbil
Model: INI 65/200
Capacity: 45 m³/h
Fusel Oil Tank No. 01 EJB-227
Model: Vertical
Capacity: 5 m³
Fusel Oil Tank No. 02 EJB-214
Model: Horizontal
Capacity: 10 m³
Fusel Oil Pump EJB-363
Manufacturer: Imbil
Model: INI 32/200
Capacity: 15 m³/h
Caustic Soda Tank EJB-215
Model: Horizontal
Capacity: 15 m³
Caustic Soda Pump EJB-372
Manufacturer: Imbil
Model: Itap 40330/2
Capacity: 5.5 m³/h
Distillery Tank Tag: EJB-369
Model: Vertical
Capacity: 90 m³
Pump No. 01 EJB-367
Manufacturer: Imbil
Capacity: 50 m³/h
Pump No. 02 EJB-368
Manufacturer: Imbil
Capacity: 50 m³/h
